SSimder MIG-140S Gasless 5 in 1 Pulse MIG Welder
Impuesto incluido.
Los gastos de envío se calculan en la pantalla de pago.
A 140A 5-in-1 gasless MIG with Pulse mode and SPOT tack welding — flux core without a gas cylinder, stick built in, Lift TIG with the optional WP17V torch, all on 110V or 220V.
Pulse mode steadies the arc on thin sheet and lowers spatter across flux MIG, Lift TIG, and Stick. SPOT mode tack-welds panels in a set time window — sheet metal, auto body, and brackets without clamps walking. Same 17.6 lb portability as the 3-in-1, with more control on the panel.
Five Functions. One 17.6 lb Machine.
Pulse and SPOT sit on top of the full flux MIG / Lift TIG / Stick platform — the same wire, the same leads, sharper control.
Pulse mode
Flux · TIG · Stick
Pulsed output keeps the arc tight on thin sheet and reduces spatter on flux core. One switch, across all three welding families.
SPOT tack welding
MIG mode
Set a spot time, touch the panel, and the machine lays a controlled tack — auto body seams, ducting, and brackets hold themselves before the final bead.
Stick welding
Thick & rusty steel
ARC FORCE keeps the arc alive on dirty, painted stock — trailer hitches, implement repairs, farm gates.
At a Glance
Every number below comes from the official spec sheet — the same figures we publish on Amazon.
| Model | MIG-140S (5-in-1 Pulse) |
|---|---|
| Processes | Flux core MIG / Lift TIG (optional torch) / Stick / Pulse / SPOT |
| Max output | 140A |
| Input voltage | 110V / 220V dual |
| MIG wire | Flux core 0.8 / 1.0 mm · 0.5–2 lb spools |
| Controls | Pulse mode (MIG/TIG/Stick) · SPOT time set (MIG) · ARC FORCE (stick) |
| Torch | 14AK MIG torch included · WP17V TIG torch sold separately |
| Included | 14AK torch, 0.5 lb flux wire, electrode holder, ground clamp, 220V conversion cord (US/CA), manual |
Built for
- ✓Sheet metal & auto body — SPOT tacks hold panels before the final bead.
- ✓Thin-gauge work — Pulse mode tightens the arc and cuts spatter.
- ✓Outdoor repairs — flux core, no gas tank, wind-proof shielding.
- ✓Upgraders from basic gasless units — same platform, real control panel.
Not built for
- ✕Aluminum welding — flux core cannot feed aluminum. Pulse MIG aluminum lives in the SD-4050 Pro.
- ✕Solid-wire gas MIG — this model runs flux core only; the MIG-140 Pro adds gas-shielded MIG.
- ✕AC TIG aluminum — aluminum TIG is the TIG-250AC's job.
How It Compares
Same MIG-140S family, three price points. Here is what the Pulse adds.
| MIG-140S (5-in-1 Pulse) | MIG-140S (3-in-1) | MIG-140 Pro (5-in-1) | |
|---|---|---|---|
| Processes | 5-in-1 | 3-in-1 | 5-in-1 |
| Pulse mode | ✓ MIG / TIG / Stick | — | ✓ Pulse MIG |
| SPOT tack welding | ✓ (MIG mode) | — | ✓ |
| Gas-shielded MIG | — flux core only | — | ✓ solid wire |
| Max output | 140A | 140A | 140A |
| Best for | Pulse & tack on a gasless budget | Lowest-cost 3-mode setup | Gas MIG in the family |
Full Specifications
| Model | MIG-140S (5-in-1 Pulse) |
|---|---|
| Input voltage | 110V / 220V dual |
| Output | 140A |
| MIG wire | Flux core 0.8 / 1.0 mm |
| Pulse | Flux MIG / Lift TIG / Stick |
| SPOT | Time-set tack welding, MIG mode |
| Machine weight | 17.6 lb (8 kg) |
What's in the Box
Everything below ships in one carton — no separate accessory orders needed to get started.
- 0114AK MIG welding torch
- 020.5 lb flux core wire
- 03Stick electrode holder
- 04Ground clamp
- 05220V conversion cord (US/CA)
- 06Operation manual
Genuine SSimder Parts
Know Your Torches - and Their Kits
Every mode on this machine runs a specific torch, and every torch runs its own wear parts. Restock the exact kit yours needs.
14AK MIG Welding Consumables - 20Pcs
Shop the Kit →
WP-17V TIG Torch Kit
Add the Torch →
E7018 Welding Rods - 10 lb
Shop the Kit →All kits are genuine SSimder parts matched to this machine's included torches. Not sure which one you need? A photo of your torch tip is all it takes — service@ssimder.com.
Frequently Asked Questions
What does Pulse mode actually do?
Pulse rapidly switches the output between a high peak and a low background current. On thin sheet that means a tighter arc, less burn-through, and less spatter to clean. On this machine, Pulse works across flux core MIG, Lift TIG, and Stick.
How does SPOT welding work on a MIG welder?
SPOT mode turns the trigger into a timed tack: set a spot duration, squeeze on the joint, and the machine fires a controlled tack of that length. It works in MIG mode and is ideal for auto body panels, ducting, and brackets.
Can it weld aluminum?
No — this model runs self-shielded flux core wire only, which is steel-family wire. For aluminum, the SD-4050 Pro welds aluminum with Pulse MIG (no spool gun needed), and the TIG-250AC handles it with AC TIG.
Is the TIG torch included?
No — Lift TIG works with the optional WP17V torch, sold separately. It uses standard WP17-series consumables, and a bundle variant with the torch included is available.
Will it run on 110V household power?
Yes — 110V or 220V input, so the same unit moves between home garage and 220V shop.
What warranty does it carry?
Every SSimder welder carries a 3-year warranty — the same policy across the line, spelled out on our warranty policy page.
